OPERATION
1. SLOWLY return the ground speed lever (GSL) (A) to
NEUTRAL and into N-DETENT.
2. Turn steering wheel until it locks.
3. Move throttle lever (B) to low idle position .
NOTE:
Avoid unnecessary idling. Stop engine if it will be
idling for longer than five minutes.
NOTE:
Brakes are au
tomatically engaged when steering
wheel is loc
kedinNEUTRALposition.
IMPORTAN T:
Before stop
ping engine, run at low idle for
approxima
tely five minutes to cool hot engine parts
(and allow
turbocharger to slow down while engine
oil pressu
re is available).
4. Turn ignition key counterclockwise to OFF position.
Figure 4.27: Operator Console
4.3.7 A djusting Caster Tread Width
The rear casters can be adjusted to a narrow tread width to allow loading and shipping without having to
remove them.
A narrow tread width also suits smaller headers by allowing more space to the uncut crop and provides more
manoeuvra bility around poles , irriga tio n inlets, or other obstacles.
A wider tread width is useful in heavy crops that produce large windrows s o that runover is reduced.
DANGER
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove
the key from the ignition before leaving the operator ’s seat for any reason.
CAUTION
Park on a flat, level surface, header on the ground, and the ground speed lever in N-DETENT position and
steering wheel locked.
147649 173 Revision A
