MacDon M155 - Engine Running, Header Engaged, Auger Header

OPERATOR’S STATION
Display (Lower or Upper Line)
Description
##.# VOLTS
Engine electrical system operating voltage.
SCROLL
SUB-MENU (Lower Line Only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■|■■■■| ####
Displays sub-menu after 2–3 Seconds. Press SELECT to
cancel. Scroll through sub-menu display with CDM switch.
Engine Run ning, Header Engaged, Auger Header
Scroll thr
ough display with cab display m odule (CDM) switch or ground speed lever (GSL) switch.
Display (L
ower or Upper Line)
Description
#####.# ENGINE HRS
Total engine operating time.
#####.# UNIT HRS
Tot al w in
drower operating time.
#####.#
HEADER HRS
Total header operating time.
##.# ACRES/HOUR
##.# HECTARES/HOUR (if Metric)
Actual cutting rate in acres (hectares)/hour.
###.# SUB ACRES
###.# SUB HECTARES (if Metric)
Area cut since last reset.
#####
# TOTAL ACRES
####
## TOTAL HECT (if M etric)
Total area cut by machine.
##.## REEL RPM
##.## R EEL SEN SOR (Flashing)
Reel rotational speed. Optional
7
Sensor disabled.
##.# AUGER SPEED Auger rotational speed (4.7–9.9).
##
## KNIFE SPEED
##
## KNIFE SENSOR (Flashing)
Kn
ife speed In strokes per minute. Optional
7
.
Se
nsor disabled.
##.# HEADER HEIGHT
##.# HEADER SENSOR (Flashing)
Distance setting (00.0–10.0) between cutterbar and ground.
Sensor disabled.
##.# HEADER ANGLE
##.# ANGLE SENSOR
Angle setting (00.0–10.0) header relative to ground. Optional
7
.
Sensor disabled.
##.# VOLTS Engine electrical system operating voltage.
FUEL|■■■■|■■■■| Level of fuel in tank.
ENGINE TEMP ### °F
ENGINE TEMP ### °C (if Metric)
Engine coolant temperature.
SCROLL
SUB-MENU (Lower Line Only)
#### KNIFE SPEED
##.# AUGER SPEED
##.## REEL RPM
##.# HEADER HEIGHT
Displays sub-menu after 2–3 Seconds. Press SELECT to cancel. Scroll
through sub-menu display with CDM switch.
Knife speed is optional
7
.
Reel rpm is o ptional
7
.
7. Optional: Available with Expansion Module installation – Whole Goods Bundle MD #B4666.
