MAINTENANCE AND SERVICING
2. Hold onto the handholds (A) on the cab front corners
and stand on the header anti-slip strips when removing
the forward field lights.
3. Remove two screws (B) and remove light bezel (C).
4. Remove light from receptacle.
Figure 5.
144: Forward Flood Lights
5. Pinch the wire retainer (A) and lift away from hooks .
6. Remove bulb (B) from body and pull wire fro m
connector (C).
IMPORTANT:
Do NOT touch the glass of the halogen bulb as
the oils or other chemicals from your skin will
cause the bulb to fail prematurely.
Figur
e 5.145: Flood Light Assembly
147649 382 Revision A
