OPERATOR’S STATION
3. Press SELECT (B) until DIAGNOSTIC MODE? is
displayed in upper line.
• NO/YES is displayed on the lower line .
4. Press right (A) arrow to select Yes. Press SELECT (B).
Figure 3.19
4: M155 Diagnostic Functions
5. Press SELECT (B) until ACTIVATE FUNCTIONS? is
displayed on the upper line.
• NO/YES is displayed on the lower line .
6. Press right (A) arrow to select YES. Press SELECT (B).
• ACTIVATE HEADER HT is displayed on the
upper line.
Figure 3.195: M155 Functions
CAUTION
Check to be sure all bystanders have cleared the area.
7. Press SELECT (E) until KNIFE DRIVE SPD XXXX is
displayed on the upper line.
IMPORTAN T:
Do NOT over speed the knife drive.
8. Press and hold HAZARD (C) button.
• Press left (B) arrow to decrease knife speed.
• Press right (D) arrow to increase knife speed.
Verify the knife drive is functioning properly.
9. Release the HAZARD (C) button. The knife will stop.
Figure 3.196: M155 Knife Drive
10. Press PROGRAM (A) to exit Programming Mode or
press SELECT (E) to proceed to next ACTIVATE
FUNCTION.
147649 145 Revision A
