OPERATION
b. Press the DISPLAY SELECTOR button (E) on the GSL to display ##.## ##.# REEL IND
18
or press FAST (C)
or SLOW (D) switch .
• The displayed value (##.##) = reel speed (rpm or mph or km/h
17
)
• The displayed value (#.##) = reel index value
c. Press FAST (C) or S LOW (D) until the d esired reel index is achieved.
NOTE:
The reel will
continue operating at the minimum reel speed setting when the ground speed drops below the set
value. The ca
b display module (CDM) d isplay (A) will flash ##.## MIN REEL (RPM or MPH or KPH) prompting
you to change
the minimum set-point or increase your ground speed if the total of the ground speed, plus the
index value i
s LESS THAN the minimum reel speed set-point.
Examples:
Windrower is operating at 8 mph with header index ON and set at -1.0.
• Display shows 7.0 -1.0 REEL IND where 7.0 (8.0-1.0) is the reel speed in mph and -1.0 is the
HEADER INDEX set tin g.
Windrower speed drops to 7.5 mph at same header index setting.
• Display shows 6.5 -1.0 REEL IND where 6.5 (7.5-1.0) is the reel speed in mph and -1.0 is the
HEADER INDEX set tin g.
Windrower is operating at 8 mph with header index ON and set at 2.0.
• Display shows: 10.0 2.0 REEL IND where 10.0 (8+2.0) is t he reel speed in m ph and 2.0 is the
HEADER INDEX set tin g.
18. REEL IND will only be displayed when operating at a ground speed faster than minimum reel speed plus header
index value.
