PRODUCT OVERVIEW
Term
Definition
NPT
National Pipe
Thread: A style of fi tting used for low pressure port openings Threads
on NPT fittings
are uniquely tapered for an interference fi t
ORB
O-ring boss: A style of fitting commonly used in port opening on manifolds, pumps,
and motors
ORFS
O-ring face seal: A style of fitting commonly used for connecting hoses and tubes
This style of fitting is also commonly called ORS, which stands for O-ring seal
PTO Power take
-off
rpm
Revolutions per minute
R-Series
header MacDon rotary disc header
RoHS (Reduction of
Hazardous Substances)
A directive by the European Union to restrict the use of certain hazardous
substances (such as hexavalent chromium used in some yellow zinc platings)
SAE Society of Automotive Engineers
Screw
A heade
d and externally threaded fastener that threads into preformed threads or
forms i
ts own threa d in one of the matin g parts
Self-Propelled (SP)
Windrower
Self-propelled machine consisting of a power unit with a header
Soft joint
A joint made with the use of a faste ner where the joining materials are com pressible
or experience relaxation over a period of time
spm
Stro
kes per minute
Tractor Agricultural type tractor
Truck
Afo
ur-wheel highway/road vehicle weighing no less than 7500 lbs (3400 kg)
Tension
Axial load placed on a bolt or screw, usually measured in pounds (lb) or Newtons (N)
TFFT
Turns from finger tight
Tor qu e
T
he product of a force X lever arm length, usually measured in foot-pounds (ft·lbf)
o
r Newton-meters (N·m)
Torque angle
A tightening procedure where the fitting is ass embled to a preco ndition (finger
tight) and then the nut is turned further a number of degrees or a number of flats to
achieve its final position
Torque-tension
The relationship between the assembly torque applied to a piece of hardware and
the axial load it induces in the bolt or screw
UCA Upper cross auger
Washer
A thin cylinder with a hole or slot located in the center that is to be used as a spacer,
load distribution element, or a locking mechanism
Windrower Power unit of a self-propelled header
WCM
Windrower control module
