Table 8.11 O-Ring Boss (ORB) Hydraulic Fittings (Adjustable)
Torque Value
35
SAE Dash Size Thread Size (in.)
ft·lbf (*in·lbf)
N·m
-2 5/16–24 *53–62 6–7
-3 3/8–24 *106–115 12–13
-4 7/16–20 14–15 19–21
-5 1/2–20 15–24 21–33
-6 9/16–18 19–21 26–29
-8 3/4–16 34–37 46–50
-10 7/8–14 55–60 75–82
-12 1-1/16–12 88–97 120–132
-14 1-3/8–12 113–124 153–168
-16 1-5/16
–12
130–14
2
176–19
3
-20 1-5/8–12 163–179 221–243
-24 1-7/8–12 199–220 270–298
-32 2-1/
2–12
245–
269
332–
365
35. Torque values shown are based on lubricated connections as in reassembly.
