PRODUCT OVERVIEW
HEADER LIFT/TILT
Type
Hydraulic Dou
ble A ctin g Cylind ers. Tilt - Option a l Hydraulic Positio n ing ,
Optional Hydr
aulic Center-Link
Function
Lift/Tilt/Float
HEADER FLOAT
Primary
Adjustment
Manual, Ex
ternal, Drawbolt With Springs (1 per side). One Inner Booster
Spring On L
eft Side.
Fine Adjustment
Hydraulic, In-Cab Switch
Automatic
Hydraulic, 3 Programmable Settings For All Headers
(Deck Shift Compensation On Draper Headers)
CAB
Type
Spring/Shock Suspension
Width
63 in. (1600 mm)
Depth
68.3 i
n. (1735 mm) (at top of window)
Height
64.6 in. (1640 m m)
Dimensions
Volume
125 cu. ft. (3540 L)
Driver
Adj
ustable Air-Ride Suspension, Seat Belt
Seat
Training
Folding, Cab Mounted, Seat Belt
Front
31.5 in. (800 mm) Blade
Wi
ndshield
Wi
per
Rear
22
in. (560 mm) Blade
Heater
24,000 Btu/h (7038 W)
Air Conditioning 28,280 Btu/h (8288 W)
Electrical Outlets One L ive, Two On Ignit ion, One Live/K eyed
Mirrors
One Inside (Transport), Two Outside (Field)
Radio
Two S peakers and Antenna Factory Installed. Radio is Dealer-Installed
SYSTEM MONITORING
Speeds
Ground (mph or km/h), Engine (rpm), Knife (spm), Disc (rpm),
Reel (rpm or mph/km/h), Conveyor (Ref. No.)
Header
Height, Angle, Float, Header Drive Load Gauge
TIRE OPTIONS (Refer to 2.3 Drive Tires, page 34 for options).
FRAME AND STRUCTU RE
Dimensions
Refer to 2.3 Drive Tires, page 34
Frame to Ground (Crop Clearance) 45.7 in. (1160 mm)
Base
9610 lbs (4360 kg)
1
Maximum GVW 21,500 lbs (9750 kg)
1
Weight
Maximum CGVW 23,100 lbs (10,480 kg)
1
1. Weights do not include options.
