MacDon M155 - Page 489

REFERENCE
Fault
Code
J1939
SPN
J1939
FMI
Lamp
Color
J1939 SPN
Description Cummins Description
45
323 655
5
Amber
Injector Cyli
nder
#05
Injector Sole
noid Cylinder #5 C ircu it – Curre nt
Below N ormal,
or Open Circuit
324 653
5
Amber
Injector Cylinder
#03
Injector Solenoid Cylin de r #3 Circuit – C urre n t
Below Normal, or Open Circuit
325 656
5
Amber
Injector Cylinder
#06
Injector Solenoid Cylin de r #6 Circuit – C urre n t
Below Normal, or Open Circuit
331 652
5
Amber
Injector C
ylinder
#02
Injector S
olenoid Cylinder #2 Circuit – Current
Below Norm
al, or Open Circuit
332 654
5
Amber
Injector Cylinder
#04
Injector Solenoid Cylin de r #4 Circuit – C urre n t
Below Normal, or Open Circuit
334 110 2 Amber
Engine Coolant
Temperature
Coolant Temperature Sensor Circuit – Data
Erratic, Intermittent, or Incorrect
338 1267 3 Amber
Vehicle
Accessories Relay
Driver
Idle Shu
tdown Vehicle A cce ssories Relay Driver
Circui
t - Vo lta ge Above Normal, or Shorte d t o
High So
urce
339 1267 4 Amber
Vehicle
Accessories Relay
Driver
Idle Shutdo w n Vehicle Accessories Relay Driver
Circuit - Voltage Below Normal, or Shorted to Low
Source
341 630 2 Amber
Calibration Memory Engine Control Module data lost - Data Erratic,
Intermittent, or Incorrect
342 630 13 Red
Cali
bration Memory
Elec
tronic Calibra tio n Code Incom p atibility - Out
of Ca
libration
343 629 12 Amber
Controller #1
Engine Control Module Warning internal hardware
failure - Bad Intelligent Device or Component
349 191 16 Amber
Transm ission
Output Shaft Speed
Transmission Output Shaft Speed - Data Valid but
Above Normal Operational Range - Moderately
Severe Level
351 627 12 Amber
C
ontroller #1
I
njector Pow er Supply - Bad Intelligent Device or
C
omponent
352 3509 4 Amber
5 Volts DC Supply Sensor Supply Voltage #1 Circuit – Voltage Below
Normal, or Shorted to Low Source
386 3509 3 Amber
5 Volts DC Supply Sensor Supply Voltage #1 Circuit – Voltage Above
Normal, or Shorted to High Source
415 100 1 Red
Engine Oil Pressure Oil Pressure Low – Data Valid but Below No rmal
Operational Range - Most Severe Level
418 97 15 Maint.
Water in Fuel
Indicator
Water in Fuel Indicator High - Data Valid but Above
Normal Operational Range – Least Severe Level
422 111 2 Amber
Coolant Level Coolant Level - Data Erratic, Intermittent, or
Incorrect
425 175 2 Amber
Oil Temperature Engine Oil Temperature - Data Erratic, Intermittent,
or Incorrect
147649 473 Revision A
