OPERATOR’S STATION
The knockout (A) is located on the exterior right
cab-forward rear corner post of the cab, under the roof,
between the horn and the light.
Figure 3.45: Knockout Location in Cab
To make your own mount, refer to dimensions template.
Use11GA.or3.0mmsteelsheet.
Figure 3
.46: Template for Antenna Mount
147649 63 Revision A
