Chassis Configuration Settings
GARD 8000 SYS RFL Electronics
April 1, 2012 7-105 973.334.3100
The actual number of the setting.
Topic:
Description of the module, for example: PLC or Audio Tone.
Slot:
The physical location within the chassis for the module; slot number.
Front/Back:
The physical location within the chassis for the module; front or back.
Top/Bottom:
Currently the location of the Comms Head.
Type:
The type of setting, for example: I/O Configuration or Checkback Settings (on-off only).
Setting Name:
What the setting does, for example: TX Enable/Disable (FSK Only) or Pretrip Timer (FSK Only).
Setting Value:
The actual value of the setting, for example: Enable or TX CF 240 Hz.
User Access Log
The GARD keeps track of login attempts, whether successful or not. The log can be saved to a PC.
(See Section 5.6.3 for more information).
Telemetry Status DBF
This is a Database Status File for the Telemetry Transmitter Module. It can be saved to a PC.
Metering Status DBF
This is a Database Status File for the Metering Module. It can be saved to a PC.
TSD Files
The GARD 8000 System supports an optional Front Panel TSD (Touch Screen Display). The
following Status database files can be extracted from the GARD.
TSD Metering Analog Values Status DBF
TSD Metering General Status DBF
TSD Metering Threshold Status DBF
TSD Telemetry Status DBF
(See Section 5.5 for further TSD information).
