Ricoh MP CW2201 Service Manual

Fixing the IC card
1. Thread the two mounting holes with the metal screw [A].
2. Fix the IC card [A] to the plastic plate [B] using the fastener [C].
3. Fix the plastic plate to the cover ( x2).
Controller Options
171

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
