Ricoh MP CW2201 Service Manual

1. Remove the left cover (p.234).
2. Use a dry cloth wrapped around the tip of a small screwdriver to clean around the openings
of the gate.
3. Use the bare tip of a small screwdriver to remove hardened ink that cannot be removed by
wiping with the cloth.
• Replace the left sump when a message alerts you that the tank is full (p.530).
Ink Tube Guide
• Damp cloth.
1. Remove the top cover (p.245).
2. Use the damp cloth to clean the back of the guide where it rubs against the frame during
normal operation [A].
PM Cleaning Points
201

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
