Ricoh MP CW2201 Service Manual

10. Remove the ground wire [A] and bracket [B] from the left hinge of the top of scanner unit.
( x2)
11. Release the boss of the right latch of the top of scanner unit on the rear of the main unit
and pull the latch up.
4. Replacement and Adjustment
258

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
