Ricoh MP CW2201 Service Manual

6. Remove the two plugs (capped) from the ink supply ports of the print head.
7. Remove the plugs [A] from two ink tubes and attach them to the ink supply ports [B].
8. Remove the protective sheet from the print head and discard it.
• When removing the protective sheet, do not pull up the ink tube too much. Or you might
accidentally remove the ink tube.
Carriage Unit
439

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
