boards.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
3-127
Boards for HiPath 3000
Peripheral Boards
Front view of IVMS8R
Figure 3-59 IVMS8R - Front View (S30122-K7379-Z)
X3 = LAN connector, 8-pin RJ45
jack
LED (yellow)
LED (green)
Lockout switch
