Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-128 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
Assignment of the RJ45 jack X3
The Ethernet (10/100BaseT) interface is accessed via the 8-pin RJ45 jack X3. The signals are
output simultaneously at the printed circuit connector X2.
Table 3-51 IVMS8 and IVMS8R - Assignment of the RJ45 Jack X3 (LAN Connector)
RJ45 Jack X3
Pin
Signal Description Printed Circuit Con-
nector X2
Pin
1Tx+Transmit+ 1
2Tx–Transmit– 3
3 Rx + Receive + 7
4–Not used
5–Not used
6 Rx – Receive – 9
7–Not used
8–Not used
