Boards for HiPath 3000
Peripheral Boards
Procedure for retrofitting a TMCAS board
Step Activity
1. Disconnect system from power supply and open system.
2. Insert TMS2 (HiPath 3750 and HiPath 3700) or TS2 (HiPath 3550).
3. ● HiPath 3750 and HiPath 3700: Insert TMCAS next to the TMS2, on the left.
● HiPath 3550 (wall housing): Insert TMCAS in slot 10.
4. Plug in TMS2/TS2-TMCAS connection cable.
5. Connect the NT to the system using the TMCAS cable.
6. Close the system and connect it to the power supply.
7. After the system has booted, both boards are entered in the system’s database
(TMS2 or TS2 and TMCAS).
8. If necessary, configure with HiPath 3000 Manager E.
Possible problems:
● TMCAS not entered in HiPath 3000 Manager E
The TMCAS is displayed automatically after the generation/regeneration of the database
in a system with a correctly inserted and connected TMCAS-TMS2/TS2 combination.
● Missing electrical connection between TMS2/TS2 and TMCAS
No TMCAS entry in the database. If a correctly configured database (with TMCAS insert-
ed offline) is then loaded into the system using generation/regeneration, the TMCAS con-
figured in HiPath 3000 Manager E appears only in the SW configuration.
● Incompatible board configuration
There is a correctly inserted TMCAS-TMS2/TS2 combination in the system. If there is a
different board entered in HiPath 3000 Manager E immediately to the left of the TMS2 (Hi-
Path 3750 and HiPath 3700) or in the HiPath 3550’s large slot, the generation is rejected.
