Siemens HiPath 3000 Service Manual

Boards for HiPath 3000
P31003-H3550-S403-4-7620, 02/05
3-270 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
boards.fm
Peripheral Boards
Installing the ECGM tool and configuring the CAS protocol converter
This section contains information on installing the ECGM tool on the service PC and for config-
uring the CAS protocol converter on the TMCAS board.
The ECGM tool supports the following actions:
● Extender, database and software download
● CAS protocol configuration
● Database programming
● Trace options
Procedure
Step Activity
1. Create directory c:\ecginst on the service PC.
2. Set up the connection to the download server (for information on this, contact your
local ITSC) and copy the following files into the directory c:\ecginst:
● e1v0xx.exe (for example, e140ah.exe)
● Ee1v0yy.exe (for example, Ee140am.exe)
● Ecgm_vzz.exe (for example Ecgm_4aa.exe)
Explanation of the variables:
● v = software version
● xx = country version of a file
● yy = file version for channels
● zz = file version for maintenance
3. Run .exe files. This will extract the following files, for example:
● Ecgm.cab (WinZip file)
● Setup.lst (LST file)
● Setup.exe (EXE file)
● 4brazil.iam (IAM file)
● Ecg_edb4.ein (EIN file)
● 4brazil.eam (EAM file)
● E140ah.sin (SIN file)
● E140ah.pnm (PNM file)
● X140pai.pnm (PNM file)
● X130aq.pnm (PNM file)
4. Execute Setup.exe file. This will create the directory ecgm and extract various
files.
5. Copy vbrazil.iyy (for example, 4brazil.iam) to the directory ecgm.
6. Run the file ecgm.exe.
