Siemens HiPath 3000 Service Manual

inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-63
Installing HiPath 3000
Installing HiPath 3800
CABLUs and open-end cables for SIPAC 1 SU connectors
Information on cable and connector assignment is provided in the board descriptions in
Chapter 3.
If Then
Slot with
SLCN
SLMA8
SLMO8
STMD3
TM2LP
TMC16
1
TMDID
1
1For U.S. only
CABLUs for connection between connector panel (SIPAC 1 SU connectors)
and MDFU-E (splitting strip for 16 TW):
● S30269-Z100-A11: 3 m in length, short stripped length for MDFU-E
slots 11-21 (see Figure 4-36)
● S30269-Z100-A21: 3 m in length, long stripped length for MDFU-E
slots 1-10 (see Figure 4-36)
CABLU with 16 TW for connection between connector panel (SIPAC 1 SU
connectors) and external patch panel S30807-K6143-X (SIVAPAC socket
terminal strip):
● S30267-Z362-A20: 2 m in length (refer to Figure 4-42)
Open-end cable (16 TW) for connection between backplane (SIPAC 1 SU
connectors) and external patch panel:
● S30267-Z192-A60: Open-end cable with 16 TW, 6 m in length
● S30267-Z192-A100: Open-end cable with 16 TW, 10 m in length
● S30267-Z192-A200: Open-end cable with 16 TW, 20 m in length
(Information on the required stripped lengths for open-end cables is
provided in Figure 4-47.)
Slot with
SLMA
SLMO2
CABLUs for connection between connector panel (SIPAC 1 SU connectors)
and MDFU-E (jumper strip for 25 TW):
● S30269-Z100-A14: 3 m in length, short stripped length for MDFU-E
slots 11-21 (see Figure 4-36)
● S30269-Z100-A24: 3 m in length, long stripped length for MDFU-E
slots 1-10 (see Figure 4-36)
CABLU with 24 TW for connection between connector panel (SIPAC 1 SU
connectors) and external patch panel S30807-K6143-X (SIVAPAC socket
terminal strip):
● S30267-Z363-A20: 2 m in length (refer to Figure 4-42)
Open-end cable (16 TW) for connection between backplane (SIPAC 1 SU
connectors) and external patch panel:
● S30267-Z192-A60: Open-end cable with 16 TW, 6 m in length
● S30267-Z192-A100: Open-end cable with 16 TW, 10 m in length
● S30267-Z192-A200: Open-end cable with 16 TW, 20 m in length
(Information on the required stripped lengths for open-end cables is
provided in Figure 4-47.)
different or no
assignment
The backplane sections of other boards and empty board slots must be cov-
ered with filler panels.
