Siemens HiPath 3000 Service Manual

inst_h3.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
4-183
Installing HiPath 3000
Installing HiPath 3550, HiPath 3350, HiPath 3500, and HiPath 3300
HiPath 3350: system overview and slots
Figure 4-105 HiPath 3350 - Wall Housing System Overview
Figure 4-106 HiPath 3350 - Slots in the Wall Housing
Optional boards
1
2
3
PSU
UPS
Cable
duct
Slot levels
CUP
Opt.1
Opt.2Opt.3
Opt.4
Opt.5
OPAL
Slot 4Slot 5 Slot 2Slot 3
CBCC
V. 2 4
CUP: Connection Unit Point
Slot levels
123
Wall
