Siemens HiPath 3000 Service Manual

cordless.fm
P31003-H3550-S403-4-7620, 02/05
HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
11-7
HiPath Cordless Office
Power-Related Capacity Limits
● HiPath 3550 and HiPath 3500
The following tables show which telephone configurations do not need an additional power
supply:
– Table 11-4, depending on the number of BS3/1 base stations connected to the central
CBCC/CBRC control board.
– Table 11-5, depending on the number of BS3/1 base stations connected to SLC16 or
SLC16N.
– Table 11-6, depending on the number of BS2/2 base stations connected to SLC16 or
SLC16N.
– Table 11-7, depending on the number of BS3/3 base stations connected to SLC16 or
SLC16N.
If extra telephone configurations are added to these, an additional power supply (by
EPSU2 or EPSU2-R) is needed.
Table 11-4 HiPath 3550, HiPath 3500 - Maximum Number of Corded Telephones De-
pending on the Number of BS3/1 Base Stations Connected to CBCC or
CBRC
Number
of BS3/1s and BS4s
connected via
1xU
P0/E
to
CBCC or CBRC
Maximum number of corded telephones
analog telephones
0 1 - 10 11 - 20 21 - 30 31 - 40 41 - 50
optiset E and optiPoint 500 telephones
1 666157534844
2 635954504641
3 605652474339
4 585349454036
5 555147423833
6 534844403531
7 504641373328
Table 11-5 HiPath 3550- Maximum Number of Corded Telephones Depending on the
Number of BS3/1 Base Stations Connected to SLC16 or SLC16N
Number
of BS3/1s and BS4s
connected via
1xU
P0/E
to
SLC16 or SLC16N
Maximum number of corded telephones
analog telephones
0 1 - 10 11 - 20 21 - 30 31 - 40 41 - 50
optiset E and optiPoint 500 telephones
1 666157534844
2 635954504641
