12-50 HiPath 3000 V5.0, HiPath 5000 V5.0, Service Manual
service.fm
Guided Maintenance
Error Class B-09 - Hardware
0 Microprocessor: Error Reload board Replace board
1 Microprocessor: Error corrected – –
2 Loadware RAM: Error Reload board Replace board
3 Loadware RAM: Error corrected – –
29 Line interruption – Check line
30 Short circuit – Check line
31 Under voltage – Check voltage
32 Thermal overload – –
34 Frame loss S
0
: Error – Check line
35 Frame loss S
0
: Error corrected – –
36 Data slip S
0
: Error – Check line
37 Data slip S
0
: Error corrected – –
38 Alarm display S
2M
: Error – Check line
39 Alarm display S
2M
: Error corrected – –
42 No signal S
2M
: Error – Check line
43 No signal S
2M
: Error corrected – –
44 Receiver remote alarm S
2M
: Error – Check line
45 Receiver remote alarm S
2M
: Error correct-
ed
––
48 Bit rate error S
2M
: Error – Check line
49 Bit rate error S
2M
: Error corrected – –
50 Loss of synchronization S
2M
: Error – Check line
51 Loss of synchronization S
2M
: Error cor-
rected
––
58 Board self-test U
P0/E
: Error – Replace board
59 Board self-test U
P0/E
: Error corrected – –
61 Overcurrent U
P0/E
: Error – Replace board
62 Overcurrent U
P0/E
: Error corrected – –
65 Out of buffers U
P0/E
/CMI: Error – –
Table 12-7 HiPath 3000 Class B Error Messages
No. Meaning Action
Recovery
Action
Technician
