Serial peripheral interface / inter-IC sound (SPI/I2S) RM0091
674/742 Doc ID 018940 Rev 1
26.7.3 SPI status register (SPIx_SR)
Address offset: 0x08
Reset value: 0x0002
Bit 2 SSOE: SS output enable
0: SS output is disabled in master mode and the SPI interface can work in multimaster
configuration
1: SS output is enabled in master mode and when the SPI interface is enabled. The SPI
interface cannot work in a multimaster environment.
Note: This bit is not used in I
2
S mode and SPI TI mode
Bit 1 TXDMAEN: Tx buffer DMA enable
When this bit is set, a DMA request is generated whenever the TXE flag is set.
0: Tx buffer DMA disabled
1: Tx buffer DMA enabled
Bit 0 RXDMAEN: Rx buffer DMA enable
When this bit is set, a DMA request is generated whenever the RXNE flag is set.
0: Rx buffer DMA disabled
1: Rx buffer DMA enabled
1514131211109876543210
Res. Res. Res. FTLVL[1:0] FRLVL[2:0] FRE BSY OVR MODF
CRC
ERR
UDR
CHSID
E
TXE RXNE
rrrrrrrrrc_w0rrrr
Bits 15:13 Reserved, must be kept at reset value.
Bits 12:11 FTLVL[1:0]: FIFO Transmission Level
These bits are set and cleared by hardware.
00: FIFO empty
01: 1/4 FIFO
10: 1/2 FIFO
11: FIFO full (considered as FULL when the FIFO threshold is greater than 1/2)
Note: These bits are not used in I²S mode
Bits 10:9 FRLVL[1:0]: FIFO reception level
These bits are set and cleared by hardware.
00: FIFO empty
01: 1/4 FIFO
10: 1/2 FIFO
11: FIFO full
Note: These bits are not used in I²S mode and in SPI receive-only mode while CRC
calculation is enabled.
Bits 8 FRE: Frame format error
This flag is used for SPI in TI slave mode and I
2
S slave mode. Refer to Section 26.3.9: SPI
error flags and Section 26.6.7: I2S error flags.
This flag is set by hardware and reset when SPIx_SR is read by software.
0: No frame format error
1: A frame format error occurred
