RM0091 Power control (PWR)
Doc ID 018940 Rev 1 73/742
6.3.4 Stop mode
The Stop mode is based on the Cortex-M0 deepsleep mode combined with peripheral clock
gating. The voltage regulator can be configured either in normal or low-power mode. In Stop
mode, all clocks in the 1.8 V domain are stopped, the PLL, the HSI and the HSE oscillators
are disabled. SRAM and register contents are preserved.
In the Stop mode, all I/O pins keep the same state as in the Run mode.
Entering Stop mode
Refer to Ta bl e 1 6 for details on how to enter the Stop mode.
To further reduce power consumption in Stop mode, the internal voltage regulator can be
put in low-power mode. This is configured by the LPDS bit of the Power control register
(PWR_CR).
If Flash memory programming is ongoing, the Stop mode entry is delayed until the memory
access is finished.
If an access to the APB domain is ongoing, The Stop mode entry is delayed until the APB
access is finished.
In Stop mode, the following features can be selected by programming individual control bits:
● Independent watchdog (IWDG): the IWDG is started by writing to its Key register or by
hardware option. Once started it cannot be stopped except by a Reset. See
Section 21.3: IWDG functional description in Section 21: Independent watchdog
(IWDG).
Table 14. Sleep-now
Sleep-now mode Description
Mode entry
WFI (Wait for Interrupt) or WFE (Wait for Event) while:
– SLEEPDEEP = 0 and
– SLEEPONEXIT = 0
Refer to the Cortex-M0 System Control register.
Mode exit
If WFI was used for entry:
Interrupt: Refer to Table 27: Vector table
If WFE was used for entry
Wakeup event: Refer to Section 11.2.3: Wakeup event management
Wakeup latency None
Table 15. Sleep-on-exit
Sleep-on-exit Description
Mode entry
WFI (wait for interrupt) while:
– SLEEPDEEP = 0 and
– SLEEPONEXIT = 1
Refer to the Cortex-M0 System Control register.
Mode exit Interrupt: Refer to Table 27: Vector table.
Wakeup latency None
