Real-time clock (RTC) RM0091

562/742 Doc ID 018940 Rev 1

24.6.10 RTC timestamp time register (RTC_TSTR)

The content of this register is valid only when TSF is set to 1 in RTC_ISR. It is cleared when

TSF bit is reset.

Address offset: 0x30

Power-on reset value: 0x0000 0000

System reset: not affected

24.6.11 RTC timestamp date register (RTC_TSDR)

The content of this register is valid only when TSF is set to 1 in RTC_ISR. It is cleared when

TSF bit is reset.

Address offset: 0x34

Power-on reset value: 0x0000 0000

System reset: not affected

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. PM HT[1:0] HU[3:0]

rrrrrrr

1514131211109876543210

Res. MNT[2:0] MNU[3:0] Res. ST[2:0] SU[3:0]

rrrrrrr rrrrrrr

Bits 31:23 Reserved, must be kept at reset value

Bit 22 PM: AM/PM notation

0: AM or 24-hour format

1: PM

Bits 21:20 HT[1:0]: Hour tens in BCD format.

Bits 19:16 HU[3:0]: Hour units in BCD format.

Bit 15 Reserved, must be kept at reset value

Bits 14:12 MNT[2:0]: Minute tens in BCD format.

Bits 11:8 MNU[3:0]: Minute units in BCD format.

Bit 7 Reserved, must be kept at reset value

Bits 6:4 ST[2:0]: Second tens in BCD format.

Bits 3:0 SU[3:0]: Second units in BCD format.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

1514131211109876543210

WDU[1:0] MT MU[3:0] Res. Res. DT[1:0] DU[3:0]

rrrrrrrr rrrrrr
