STMicroelectronics STM32F05 series User Manual

Inter-integrated circuit (I
2
C) interface RM0091
500/742 Doc ID 018940 Rev 1
Table 69. Examples of timings settings for f
I2CCLK
= 48 MHz
Parameter
Standard mode Fast Mode Fast Mode Plus
10 kHz 100 kHz 400 kHz 1000 kHz
PRESC 0xB 0xB 5 5
SCLL 0xC7 0x13 0x9 0x3
t
SCLL
200 x 250 ns = 50 µs 20 x 250 ns = 5.0 µs 10 x 125 ns = 1250 ns 4 x 125 ns = 500 ns
SCLH 0xC3 0xF 0x3 0x1
t
SCLH
196 x 250 ns = 49 µs 16 x 250 ns = 4.0 µs 4 x 125 ns = 500 ns 2 x 125 ns = 250 ns
t
SCL
(1)
~100 µs
(2)
~10 µs
(2)
~2500 ns
(3)
~875 ns
(4)
SDADEL 0x2 0x2 0x3 0x0
t
SDADEL
2 x 250 ns = 500 ns 2 x 250 ns = 500 ns 3 x 125 ns = 375 ns 0 ns
SCLDEL 0x4 0x4 0x3 0x1
t
SCLDEL
5 x 250 ns = 1250 ns 5 x 250 ns = 1250 ns 4 x 125 ns = 500 ns 2 x 125 ns = 250 ns
1. The SCL period t
SCL
is greater than t
SCLL
+ t
SCLH
due to the SCL internal detection delay. Values provided for t
SCL
are only
examples.
2. t
SYNC1 +
t
SYNC2
minimum value is 4x t
I2CCLK
= 83.3 ns. Example with t
SYNC1 +
t
SYNC2
= 1000 ns
3. t
SYNC1 +
t
SYNC2
minimum value is 4x t
I2CCLK
= 83.3 ns. Example with t
SYNC1 +
t
SYNC2
= 750 ns
4. t
SYNC1 +
t
SYNC2
minimum value is 4x t
I2CCLK
= 83.3 ns. Example with t
SYNC1 +
t
SYNC2
= 250 ns
