RM0091 Universal synchronous asynchronous receiver transmitter (USART)

Doc ID 018940 Rev 1 631/742

25.7.10 Receive data register (USART_RDR)

Address offset: 0x24

Reset value: Undefined

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res Res Res Res Res Res Res Res Res Res Res Res Res Res Res Res

1514131211109876543210

Res Res Res Res Res Res Res RDR[8:0]

rrrrrrrrr

Bits 31:9 Reserved, must be kept at reset value.

Bits 8:0 RDR[8:0]: Receive data value

Contains the received data character.

The RDR register provides the parallel interface between the input shift register and the

internal bus (see Figure 228).

When receiving with the parity enabled, the value read in the MSB bit is the received parity

bit.
