RM0091 Power control (PWR)
Doc ID 018940 Rev 1 75/742
Entering Standby mode
Refer to Ta bl e 1 7 for more details on how to enter Standby mode.
In Standby mode, the following features can be selected by programming individual control
bits:
Independent watchdog (IWDG): the IWDG is started by writing to its Key register or by
hardware option. Once started it cannot be stopped except by a reset. See
Section 21.3: IWDG functional description in Section 21: Independent watchdog
(IWDG).
real-time clock (RTC): this is configured by the RTCEN bit in the Backup domain control
register (RCC_BDCR)
Internal RC oscillator (LSI): this is configured by the LSION bit in the Control/status
register (RCC_CSR).
External 32.768 kHz oscillator (LSE): this is configured by the LSEON bit in the Backup
domain control register (RCC_BDCR)
Exiting Standby mode
The microcontroller exits the Standby mode when an external reset (NRST pin), an IWDG
reset, a rising edge on one of the enabled WKUPx pins or the rising edge of an RTC alarm
occurs (see Figure 227: RTC block diagram). All registers are reset after wakeup from
Standby except for Power control/status register (PWR_CSR).
After waking up from Standby mode, program execution restarts in the same way as after a
Reset (boot pin sampling, option bytes loading, reset vector is fetched, etc.). The SBF status
flag in the Power control/status register (PWR_CSR) indicates that the MCU was in Standby
mode.
Refer to Ta bl e 1 7 for more details on how to exit Standby mode.
I/O states in Standby mode
In Standby mode, all I/O pins are high impedance except:
Reset pad (still available)
PC13, PC14 and PC15 if configured by RTC or LSE
WKUPx pins
Table 17. Standby mode
Standby mode Description
Mode entry
WFI (Wait for Interrupt) or WFE (Wait for Event) while:
Set SLEEPDEEP in Cortex-M0 System Control register
Set PDDS bit in Power Control register (PWR_CR)
Clear WUF bit in Power Control/Status register (PWR_CSR)
Mode exit
WKUP pin rising edge, RTC alarm event’s rising edge, external Reset in
NRST pin, IWDG Reset.
Wakeup latency Reset phase
