RM0091 Power control (PWR)

Doc ID 018940 Rev 1 81/742

6.4.3 PWR register map

The following table summarizes the PWR registers.

Refer to Section 2.2.2 on page 37 for the register boundary addresses.

Table 18. PWR register map and reset values

Offset Register

0x000

PWR_CR

Res.

DBP

PLS[2:0]

PVDE

CSBF

CWUF

PDDS

LPDS

Reset value 000000000

0x004

PWR_CSR

Res.

EWUP2

EWUP1

Res.

PVDO

SBF

WUF

Reset value 00 000
