RM0091 Inter-integrated circuit (I

C) interface

Doc ID 018940 Rev 1 533/742

23.7.11 Transmit data register (I2Cx_TXDR)

Address offset: 0x28

Reset value: 0x0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

1514131211109876543210

Res. Res. Res. Res. Res. Res. Res. Res. TXDATA[7:0]

Bits 31:8 Reserved, must be kept at reset value.

Bits 7:0 TXDATA[7:0] 8-bit transmit data

Data byte to be transmitted to the I2C bus.

Note: These bits can be written only when TXE=1.
