RM0091 Universal synchronous asynchronous receiver transmitter (USART)
Doc ID 018940 Rev 1 629/742
25.7.9 Interrupt flag clear register (USART_ICR)
Address offset: 0x20
Reset value: 0x0000
Bit 2 NF: Noise detected flag
This bit is set by hardware when noise is detected on a received frame. It is cleared by
software, writing 1 to the NFCF bit in the USART_ICR register.
0: No noise is detected
1: Noise is detected
Note: 1. This bit does not generate an interrupt as it appears at the same time as the RXNE
bit which itself generates an interrupt. An interrupt is generated when the NF flag is set
during multi buffer communication if the EIE bit is set.
2. When the line is noise-free, the NF flag can be disabled by programming the
ONEBIT bit to 1 to increase the USART tolerance to deviations (Refer to
Section 25.5.5: Tolerance of the USART receiver to clock deviation on page 587).
Bit 1 FE: Framing error
This bit is set by hardware when a de-synchronization, excessive noise or a break character
is detected. It is cleared by software, writing 1 to the FECF bit in the USART_ICR register.
In Smartcard mode, in transmission, this bit is set when the maximum number of transmit
attempts is reached without success (the card NACKs the data frame).
An interrupt is generated if EIE = 1 in the USART_CR1 register.
0: No Framing error is detected
1: Framing error or break character is detected
Bit 0 PE: Parity error
This bit is set by hardware when a parity error occurs in receiver mode. It is cleared by
software, writing 1 to the PECF in the USART_ICR register.
An interrupt is generated if PEIE = 1 in the USART_CR1 register.
0: No parity error
1: Parity error
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res Res Res Res Res Res Res Res Res Res Res WUCF Res Res CMCF Res
w_r0 w_r0
1514131211109876543210
Res Res Res EOBCF RTOCF Res CTSCF LBDCF Res TCCF Res
IDLEC
F
ORECF NCF FECF PECF
w_r0 w_r0 w_r0 w_r0 w_r0 w_r0 w_r0 w_r0 w_r0 w_r0
Bits 31:21 Reserved, must be kept at reset value.
Bit 20 WUCF: Wakeup from Stop mode clear flag
Writing 1 to this bit clears the WUF flag in the USART_ISR register.
Note: If the USART does not support the wakeup from Stop feature, this bit is reserved and
forced by hardware to ‘0’.
Bits 19:18 Reserved, must be kept at reset value.
Bit 17 CMCF: Character match clear flag
Writing 1 to this bit clears the CMF flag in the USART_ISR register.
Bits 16:13 Reserved, must be kept at reset value.
