General-purpose timers (TIM15/16/17) RM0091
382/742 Doc ID 018940 Rev 1
Figure 158. Counter timing diagram, internal clock divided by 4
Figure 159. Counter timing diagram, internal clock divided by N
Figure 160. Counter timing diagram, update event when ARPE=0 (TIMx_ARR not
preloaded)
CK_PSC
0000 0001
CNT_EN
Timer clock = CK_CNT
Counter register
Update interrupt flag (UIF)
0035
0036
Counter overflow
Update event (UEV)
Timer clock = CK_CNT
Counter register
00
1F
20
Update interrupt flag (UIF)
Counter overflow
Update event (UEV)
CK_PSC
CK_PSC
00
CEN
Timer clock = CK_CNT
Counter register
Update interrupt flag (UIF)
Counter overflow
Update event (UEV)
01 02 03 04 05 06 0732 33 34 35 3631
Auto-reload register
FF 36
Write a new value in TIMx_ARR
