RM0091 System window watchdog (WWDG)

Doc ID 018940 Rev 1 467/742

22.6.4 WWDG register map

The following table gives the WWDG register map and reset values.

Refer to Section 2.2.2 on page 37 for the register boundary addresses.

Table 60. WWDG register map and reset values

Offset Register

0x00

WWDG_CR

Res.

WDGA

T[6:0]

Reset value 01111111

0x04

WWDG_CFR

Res.

EWI

WDGTB1

WDGTB0

W[6:0]

Reset value 0001111111

0x08

WWDG_SR

Res.

EWIF

Reset value 0
