RM0091 Real-time clock (RTC)
Doc ID 018940 Rev 1 565/742
24.6.14 RTC tamper and alternate function configuration register
(RTC_TAFCR)
Address offset: 0x40
Power-on reset value: 0x0000 0000
System reset: not affected
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res.
PC15
MODE
PC15
VALUE
PC14
MODE
PC14
VALUE
PC13
MODE
PC13
VALUE
Res. Res.
rw rw rw rw rw rw
1514131211109876543 2 10
TA MP P
UDIS
TAMPPRCH[1:0
]
TAMPFLT[1:0] TAMPFREQ[2:0]
TA MP T
S
TA MP 3
-TRG
TA MP 3
E
TA MP 2
TRG
TA MP 2
E
TA MP IE
TA MP 1
TRG
TAM P1
E
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bit 31:24 Reserved, must be kept at reset value.
Bit 23 PC15MODE: PC15 mode
0: PC15 is controlled by the GPIO configuration registers. Consequently PC15 is floating in
Standby mode.
1: PC15 is forced to push-pull output if LSE is disabled.
Bit 22 PC15VALUE: PC15 value
If the LSE is disabled and PC15MODE = 1, PC15VALUE configures the PC15 output data.
Bit 21 PC14MODE: PC14 mode
0: PC14 is controlled by the GPIO configuration registers. Consequently PC14 is floating in
Standby mode.
1: PC14 is forced to push-pull output if LSE is disabled.
Bit 20 PC14VALUE: PC14 value
If the LSE is disabled and PC14MODE = 1, PC14VALUE configures the PC14 output data.
Bit 19 PC13MODE: PC13 mode
0: PC13 is controlled by the GPIO configuration registers. Consequently PC13 is floating in
Standby mode.
1: PC13 is forced to push-pull output if all RTC alternate functions are disabled.
Bit 18 PC13VALUE: RTC_ALARM output type/PC13 value
If PC13 is used to output RTC_ALARM, PC13VALUE configures the output configuration:
0: RTC_ALARM is an open-drain output
1: RTC_ALARM is a push-pull output
If all RTC alternate functions are disabled and PC13MODE = 1, PC13VALUE configures the
PC13 output data.
Bits 17:16 Reserved, must be kept at reset value.
Bit 15 TAMPPUDIS: RTC_TAMPx pull-up disable
This bit determines if each of the RTC_TAMPx pins are pre-charged before each sample.
0: Precharge RTC_TAMPx pins before sampling (enable internal pull-up)
1: Disable precharge of RTC_TAMPx pins.
