RM0091 Device electronic signature

Doc ID 018940 Rev 1 735/742

30.2 Memory size data register

30.2.1 Flash size data register

Base address: 0x1FFF F7CC

Address offset: 0x00

Read only = 0xXXXX where X is factory-programmed

1514131211109876543210

FLASH_SIZE

rrrrrrrrrrrrrrrr

Bits 15:0 FLASH_SIZE[15:0]: Flash memory size

This bitfield indicates the size of the device Flash memory expressed in Kbytes.

As an example, 0x040 corresponds to 64 Kbytes.
