STMicroelectronics STM32F05 series User Manual

RM0091
Doc ID 018940 Rev 1 37/742
2.2 Memory organization
2.2.1 Introduction
Program memory, data memory, registers and I/O ports are organized within the same linear
4-Gbyte address space.
The bytes are coded in memory in Little Endian format. The lowest numbered byte in a word
is considered the word’s least significant byte and the highest numbered byte the most
significant.
The addressable memory space is divided into 8 main blocks, each of 512 MB.
All the memory areas that are not allocated to on-chip memories and peripherals are
considered “Reserved”). For the detailed mapping of available memory and register areas,
please refer to the Memory map and register boundary addresses chapter and peripheral
chapters.
2.2.2 Memory map and register boundary addresses
The following table gives the memory map and boundary addresses of the peripherals
available in all STM32F05xxx devices.
Table 2. STM32F05xxx memory map and peripheral register boundary addresses
Bus Boundary address Size Peripheral Peripheral register map
0xE000 0000 - 0xE00F FFFF 1MB
Cortex M0 internal
peripherals
0x4800 1800 - 0x5FFF FFFF ~384 MB Reserved
AHB2
0x4800 1400 - 0x4800 17FF 1KB GPIOF Section 8.4.11 on page 133
0x4800 1000 - 0x4800 13FF 1KB Reserved
0x4800 0C00 - 0x4800 0FFF 1KB GPIOD Section 8.4.11 on page 133
0x4800 0800 - 0x4800 0BFF 1KB GPIOC Section 8.4.11 on page 133
0x4800 0400 - 0x4800 07FF 1KB GPIOB Section 8.4.11 on page 133
0x4800 0000 - 0x4800 03FF 1KB GPIOA Section 8.4.11 on page 133
0x4002 4400 - 0x47FF FFFF ~128 MB Reserved
AHB1
0x4002 4000 - 0x4002 43FF 1 KB TSC Section 27.6.11 on page 697
0x4002 3400 - 0x4002 3FFF 3 KB Reserved
0x4002 3000 - 0x4002 33FF 1 KB CRC Section 5.4.5 on page 66
0x4002 2400 - 0x4002 2FFF 3 KB Reserved
0x4002 2000 - 0x4002 23FF 1 KB FLASH interface Section 3.6 on page 58
0x4002 1400 - 0x4002 1FFF 3KB Reserved
0x4002 1000 - 0x4002 13FF 1 KB RCC Section 7.4.15 on page 116
0x4002 0400 - 0x4002 0FFF 3KB Reserved
0x4002 0000 - 0x4002 03FF 1 KB DMA Section 10.4.7 on page 155
0x4001 8000 - 0x4001 FFFF 32 KB Reserved
