RM0091
38/742 Doc ID 018940 Rev 1
APB
0x4001 5C00 - 0x4001 7FFF 9KB Reserved
0x4001 5800 - 0x4001 5BFF 1 KB DBGMCU
0x4001 4C00 - 0x4001 57FF 3KB Reserved
0x4001 4800 - 0x4001 4BFF 1 KB TIM17 Section 18.6.16 on page 438
0x4001 4400 - 0x4001 47FF 1 KB TIM16 Section 18.6.16 on page 438
0x4001 4000 - 0x4001 43FF 1 KB TIM15 Section 18.5.18 on page 420
0x4001 3C00 - 0x4001 3FFF 1KB Reserved
0x4001 3800 - 0x4001 3BFF 1 KB USART1 Section 25.7.12 on page 633
0x4001 3400 - 0x4001 37FF 1KB Reserved
0x4001 3000 - 0x4001 33FF 1 KB SPI1/I2S1 Section 26.7.10 on page 680
0x4001 2C00 - 0x4001 2FFF 1 KB TIM1 Section 15.4.21 on page 290
0x4001 2800 - 0x4001 2BFF 1KB Reserved
0x4001 2400 - 0x4001 27FF 1 KB ADC Section 12.12.11 on page 203
0x4001 0800 - 0x4001 23FF 7KB Reserved
0x4001 0400 - 0x4001 07FF 1 KB EXTI Section 11.3.7 on page 181
0x4001 0000 - 0x4001 03FF 1 KB SYSCFG + COMP
Section 9.1.7 on page 140
Section 14.4.2 on page 222
0x4000 8000 - 0x4000 FFFF 32 KB Reserved
Table 2. STM32F05xxx memory map and peripheral register boundary addresses
Bus Boundary address Size Peripheral Peripheral register map
