Real-time clock (RTC) RM0091

560/742 Doc ID 018940 Rev 1

24.6.8 RTC sub second register (RTC_SSR)

Address offset: 0x28

Power-on reset value: 0x0000 0000

System reset: 0x0000 0000 when BYPSHAD = 0. Not affected when BYPSHAD = 1.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

1514131211109876543210

SS[15:0]

rrrrrrrrrrrrrrrr

Bits31:16 Reserved, must be kept at reset value

Bits 15:0 SS: Sub second value

SS[15:0] is the value in the synchronous prescaler’s counter. The fraction of a second is

given by the formula below:

Second fraction = ( PREDIV_S - SS ) / ( PREDIV_S + 1 )

Note: SS can be larger than PREDIV_S only after a shift operation. In that case, the correct

time/date is one second less than as indicated by RTC_TR/RTC_DR.
