Serial peripheral interface / inter-IC sound (SPI/I2S) RM0091
672/742 Doc ID 018940 Rev 1
26.7.2 SPI control register 2 (SPIx_CR2)
Address offset: 0x04
Reset value: 0x0000
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res.
LDMA
_TX
LDMA
_RX
FRXT
H
DS [3:0] TXEIE RXNEIE ERRIE FRF NSSP SSOE TXDMAEN RXDMAEN
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bit 15 Reserved, must be kept at reset value.
Bit 14 LDMA_TX: Last DMA transfer for transmission
This bit is used in data packing mode, to define if the total number of data to transmit by
DMA is odd or even. It has significance only if the TXDMAEN bit in the SPIx_CR2 register is
set and if packing mode is used (data length =< 8-bit and write access to SPIx_DR is 16-bit
wide). It has to be written when the SPI is disabled (SPE = 0 in the SPIx_CR1 register).
0: Number of data to transfer is even
1: Number of data to transfer is odd
Note: 1. Refer to Procedure for disabling the SPI on page 644 if the CRCEN bit is set.
2. This bit is not used in I²S mode.
Bit 13 LDMA_RX: Last DMA transfer for reception
This bit is used in data packing mode, to define if the total number of data to receive by DMA
is odd or even. It has significance only if the RXDMAEN bit in the SPIx_CR2 register is set
and if packing mode is used (data length =< 8-bit and write access to SPIx_DR is 16-bit
wide). It has to be written when the SPI is disabled (SPE = 0 in the SPIx_CR1 register).
0: Number of data to transfer is even
1: Number of data to transfer is odd
Note: 1. Refer to Procedure for disabling the SPI on page 644 if the CRCEN bit is set.
2. This bit is not used in I²S mode.
Bit 12 FRXTH: FIFO reception threshold
This bit is used to set the threshold of the RXFIFO that triggers an RXNE event
0: RXNE event is generated if the FIFO level is greater than or equal to 1/2 (16-bit)
1: RXNE event is generated if the FIFO level is greater than or equal to 1/4 (8-bit)
Note: This bit is not used in I²S mode.
