Display
WARNING ā When the temperature of the display case reaches 65Ā° C (149 Ā° F) the display shows the following:
WARNING!īHOTīSURFACE, DOīNOTīTOUCH. The display will dim the screen until the temperature returns to
normal. Use caution when touching the display when this warning is visible.
Implement master switch
WARNING ā When the implement is down and the master switch is in the On position, the machine is fully
operational. Take all necessary precautions to ensure user safety. Failure to do so could result in injury or death.
Cautions
Calibration
CAUTION ā Obstacles in the field can cause collisions, which may injure you and damage the vehicle. If an
obstacle in the field makes it unsafe to continue the Automated Deadzone calibration, stop the vehicle and turn
the steering wheel to disengage the system.
1) Wait until the display prompts you that the phase is ready to begin.
2) Look at the screen to determine whether the next phase will require a left or right turn.
3) Reposition the vehicle so that the turn will use the space that you have available.
4) Tap the button to begin the next phase.
CAUTION ā The wheels can move abruptly during the Steering Proportional Gain procedure while the Autopilot
system tests the hydraulic response to its steering commands. To avoid injury, be prepared for vehicle movement.
Display
CAUTION ā If you leave the display powered on after shutting off the vehicle's ignition, the display power can
drain the battery.
CAUTION ā Do not press on the screen with a sharp item, such as a pencil. You may damage the surface of the
screen.
CAUTION ā Do not apply glass cleaner directly to the touchscreen.
Version 1.075, Revision C TMX-2050 Display User Guide 11
Safety Information
