EZ-Pilot system setup 6 Vehicles
EZ-Pilot system setup
The EZ-Pilot system turns the steering wheel for you with an electric motor drive. It uses GNSS
guidance from the TMX-2050 display.
Initial setup steps are:
l Guidance selection for the EZ-Pilot system, 167
l Controller settings for EZ-Pilot system, 167
l Vehicle measurements for EZ-Pilot system, 169
l Steering speed settings for EZ-Pilot system, 168
Guidance selection for the EZ-Pilot system
WARNING – Auto guidance systems cannot avoid items in the field such as obstacles. Make sure you are
adequately trained to operate the auto guidance system.
1. Navigate to the GUIDANCE section of the vehicle setup panel:
a.
At the Home screen, tap . The Vehicle setup panel displays.
b. At the list on the left-hand side of the setup panel, tap the name of the vehicle you want to
edit. The display changes the list item to a blue background with white text.
c. Tap Edit, then GUIDANCE.
2.
At the SELECTION section,tap EZ-Pilot.
WARNING – Many large and sudden changes in satellite geometry caused by blocked satellites can cause
significant position shifts. If operating under these conditions, auto-guidance systems can react abruptly. To
avoid possible personal injury or damage to property under these conditions, disable the auto-guidance
system and take manual control of the vehicle until conditions have cleared.
3. Tap Next to set up the controller orientation. See Controller settings for EZ-Pilot system, 167.
Controller settings for EZ-Pilot system
The EZ-Pilot system ueses the IMD-600 to provide roll compensation when the vehicle is on a slope
or drives over a bump. For roll compensation to work correctly, the IMD-600 must be calibrated.
IMD stands for Inertial Measurement Device.
To set up the IMD-600 controller, you must indicate the position/orientation of the controller as it is
currently installed in the vehicle.
For example, if the controller is positioned with the input jacks of the controller facing to the left side
of your vehicle, you indicate this in the TMX-2050 display.
Version 1.075, Revision C TMX-2050 Display User Guide 167
