10 Operations Guidance patterns
l AB guidance line creation (Run screen), 251
l A+ guidance line creation (Run screen), 252
l Curved line creation (Run screen), 252
9. Continue driving around the field until you are near your starting point.
ll If Auto-Close is on: When you reach auto-close distance , the display will connect the
vehicle's current location to the starting point with a straight line and save the pattern.
l
If Auto-Close is off: Drive to the beginning point and tap . The display will connect the
vehicle's current location to the starting point with a straight line and save the pattern.
To set the auto close feature, see Patterns settings, 83.
10. When finished, the display:
a. Saves the headland pattern with a unique name (for example, HL01).
b. Generates an inner boundary and an outer boundary based on the recorded path and the
width of the implement. The headland boundaries are saved with a unique name related
to the headland (for example, HL01 inner boundary and HL01 outer boundary).
c. Generates an infill swath based on the number of circuits selected and the width of the
implement. The infill swath is saved with a unique name related to the headland (for
example, DefaultInfillSwath).
11.
To cancel the pattern creation, tap .
Infill pattern shift
To shift the infill pattern, complete the following steps.
1.
At the Run screen, open the Field Manager by tapping .
2. Tap GUIDANCEPATTERNS.
3. In the list of patterns, tap to select the infill pattern you want to shift, and tap Activate.
4.
Tap Shift. The Shift Pattern tool displays.
254 TMX-2050 Display User Guide Version 1.075, Revision C
