Target Rate Set test rates to use for Rate 1 and Rate 2.
Master Switch Indicates whether the Field-IQ Master Switch is on or off.
Applied Rate The applied rate for comparison to the
Target Rate
.
Integral Gain (for Servo
drives only)
If the drive is slow to come up to rate, increase the
Integral Gain
and turn on
Boost (Feed Forward)
.
If the applied rate is erratic, decrease the Integral Gain.
Proportional Gain
(for PWM drives only)
If the drive is slow to come up to rate, increase the
Proportional
Gain
and turn on
Boost (Feed Forward)
.
If the applied rate is erratic, decrease the Proportional Gain.
Minimum Response If the drive is not responding, increase the
Minimum Response
. If
the system has large fluctuations in applied rate, decrease the
minimum response.
Minimum Position (for
PWMdrives only)
Minimum Position
is the duty cycle the system commands to
when all sections are off and you are using
Lock in Minimum
Position
(see
Rate control, 202
).
Allowable Error
If the Applied Rate is less than this amount away from the target
rate, the system will not send commands to adjust the rate.
Boost (Feed Forward) If the drive is slow to come up to rate, increase the
Integral/Proportional Gain
and turn on
Boost (Feed Forward)
.
8. Tap Next to continue to the Information section.
9. Review the calibration results. The minimum and maximum values indicate the speed and flow
ranges that will apply during operations.
10.
To accept the calibration, tap .
For information on: See:
Diagnostics
Boom Height Diagnostics, 300
Control and adjustments
during operation
Boom height control operation, 276
Virtual tank/bin
If you have the Field-IQsystem's Rate Control, you can use an on-screen (virtual) tank to monitor
tank or bin levels based on the amount of material applied.
