11 Diagnostics / troubleshooting Boom Height Diagnostics
Boom Height Diagnostics
At the Diagnostics panel, tap Performance under Boom Height.
Sensors
This information is display only.
Item Explanation
Status The sensor's status: connected or disconnected
S/N The serial number for the sensor. The display reads the serial numbers from
the installed sensors.
Version Firmware version of the sensor
Sensor Height Current height of sensor
Side Offset The distance from the center line of the sensor to the hinge point of the boom.
(Does not apply to the center section.)
Nozzle Offset The distance from the bottom edge of the sensor cone to the outlet of the
spray nozzle tip.
Boom Status
Valve Module
This information is display only.
Item Explanation
Module Type of module
Status Connected, disconnected
S/N Serial number of valve module
Version Version of firmware
Boom ControlStatus
This information is display only.
Item Explanation
Control Left, right or center
Valve Command Normal, inverted
300 TMX-2050 Display User Guide Version 1.075, Revision C
