Mapping settings 3 Display settings
Mapping settings
These settings control guidance mapping features available on the Run screen.
Setting Tap to view or change...
Map Background Selection The ground color for the
Run
screen. Options are:
l Color: Brown, green or grey
l Color with texture
l Color with gridlines
Map Color Scheme Day or night mode.
Map Orientation Which point of view displays on the
Run
screen when following the
position of the vehicle. Orientation options:North Up or Vehicle Up.
Record Coverage When
Engaged
The system can switch on coverage when auto guidance is engaged,
and switch off coverage when it is not engaged. Option for this
setting is on or off.
To access the Mapping settings:
1.
Tap .
2.
Tap .
3. Tap Mapping.
Patterns settings
At pattern settings, you can:
l Activate the auto close feature to use when you create boundaries and headlands
l Activate smoothing for curves and turn radius when traveling on guidance lines
l Customize the tight turn warning angle and look-ahead time
Curve Features
Setting Tap to view or change...
Curve Smoothing The feature on or off. When curve smoothing is on, the system
smooths out the guidance curve, making it wider.
Version 1.075, Revision C TMX-2050 Display User Guide 83
