8 Implements Boom height control
Boom height control
Note – For the correct connection of equipment, refer to the Connecting the Field-IQ system Crop
Input Control Systems chapter in the TMX-2050 Display Cabling Guide.
Implement setup includes Boom Height if you have a boom height control feature unlocked on the
device.
Before setting up Field-IQ Boom Height Control, you must complete the following:
l Unlock and install Field-IQ Boom Height Control.
l Add, configure and calibrate a vehicle. See Add a vehicle, 140.
l Set up the implement. See Implement setup, 188.
Note – A SIMmust be present before you can use Boom Height Control.
To set up Field-IQ Boom Height Control, complete the following settings:
1. Boom height control setup, 210
2. Sensor location, 211
3. Operation settings, 212
For information on: See:
Calibrating boom height
Calibrate boom height control, 215
Diagnostics
Boom Height Diagnostics, 300
Control during operation
Boom height control operation, 276
Adjustment during
operation
Boom height adjustments, 278
Boom height control setup
1.
At the Control section of the Boom Height settings, review and make changes to the settings as
appropriate.
Tap.... To....
Boom Height Turn the feature on or off.
TM-200 Module S/N Choose the appropriate serial number of the TM-200 Module.
210 TMX-2050 Display User Guide Version 1.075, Revision C
