Trimble TMX-2050 - Guidance System Setup and Calibration

6 Vehicles Autopilot system setup
Autopilot system setup
Settings for the Autopilot system include:
l The type of platform for the Autopilot system
l The origin of the vehicle profile
l Controller and sensor settings
l Vehicle measurements
l Calibrations
Guidance system settings for Autopilot system
WARNING – Auto guidance systems cannot avoid items in the field such as obstacles. Make sure you are
adequately trained to operate the auto guidance system.
1. Navigate to the GUIDANCE section of the vehicle setup panel:
a.
At the Home screen, tap . The Vehicle setup panel displays.
b. At the list on the left-hand side of the setup panel, tap the name of the vehicle you want to
edit. The display changes the list item to a blue background with white text.
c. Tap Edit, then GUIDANCE.
2.
At the SELECTIONS section, complete the settings:
Tap... Explanation
Selection
Autopilot
Autopilot Platform
The appropriate platform for your vehicle.
146 TMX-2050 Display User Guide Version 1.075, Revision C
