8 Implements Application control
Setting Options
Serial Number Select the serial number of the Section Control Module installed at
this location. The display reads the serial numbers from the installed
modules.
Number of Sections Enter the number of sections physically wired into this module (up to
12 sections per control module).
2.
Tap when you have completed the settings for each module. Then tap Next to continue to
Width, 200.
Note – When you upgrade the TMX-2050 display firmware, the firmware for Field-IQ modules are
also upgraded. There are no additional steps required to upgrade modules.
Width
1. At the WIDTHsection for Section Control, review the width of each section per module.
2.
To change a width of a the section, tap it. Begin with the first one on the left, and work from left
to right.
3. The system will not allow you to change the width of the sections to be more or less than the
total width of the implement.
4. Tap Next to continue to Latencies, 200.
Latencies
Latency refers to the delay between when the command occurs (to turn a section on or off) and
when application of the material actually starts or stops.
1.
At the Latencies section for Section Control, review and make changes as necessary to the
settings.
Tap... To...
On Latency
Enter the length of time (seconds) from when a section is turned on
to when the system begins to apply material.
Off Latency
Enter the length of time (seconds) from when a section is turned off
to when the system stops applying material.
200 TMX-2050 Display User Guide Version 1.075, Revision C
