10 Operations Guidance patterns
1.
Tap to open the Field Manager. Field Manager opens to the Field Overview section.
2. Tap GUIDANCEPATTERNS.
3. Tap on the line, headland or pivot area in the list on the right-hand side.
4.
To activate:
ll
An inactive pattern, tap (red).
l
An inactive guidance line, tap (red).
5.
To de-activate:
ll
An active pattern, tap (black).
l
An active guidance line, tap (black).
For information on: See:
Field Manager
Field Manager, 61
Guidance pattern adjustment (Run screen)
To adjust guidance while performing field activities, at the Run screen, tap .
The system displays the guidance adjustment buttons.
Note – These adjustments are called "temporary" because they are not stored in the system. After
reboot or power off, the system returns to the original settings.
Button Use to...
Nudge Moves the position of the vehicle in a perpendicular direction (left
or right) to the line you are engaged on currently.
To adjust the size of the increments, see Steering and guidance
settings, 85.
Remark
Temporarily move the line or pattern to the vehicle's current
location or the value entered by you.
260 TMX-2050 Display User Guide Version 1.075, Revision C
